• Linear rate of welding 6-21m/min
  • Production capability 15~38Cans/min
  • Applicable can diameter Φ220~Φ300mm
  • Applicable can height 250~450mm
  • Applicable material Tinplate steel-based
  • Applicable material thickness 0.25~0.42mm
  • Seam welding landing 0.8mm 1.0mm 1.2mm
  • Seam point distance 0.5-0.8mm
  • Applicable copper wire diameter 1.5mm 1.7mm
  • Cooling water Temperature 12~18°CPressure:0.4-0.5Mpa Discharge 12L/min
  • Compressed air consumption 400 L/min
  • Pressure of compressed air 0.5Mpa-0.7Mpa
  • Power 380V±5% 50HZ
  • Total power 63KVA
  • Packed Dimension 2300x1800x2000mm
  • Packed Weight 2500Kg
